Smoke Detector with Relay Output from China manufacturer

Price:	5.0~12.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: SNC-300-SR

Production Capacity: 450000/Month

Delivery Date: 15-30days

WIRING: 4-wire

QUIESCENT CURRENT: 60uA

POWER SUPPLY: 24V DC

HUMIDITY: 0% to 95% RH No Condensatio...

APPROVAL: EN:0086-CPD-587752;UL:S2521...

Means of Transport: Ocean,Land,Air

Packing: 1pc/box, 100pcs/ctn

Brand Name: Numens

RELAY: relay output

ALARM CURRENT: 35mA

TEMPERATURE: -10℃ to +55℃

CERTIFICATED: EN 54-5/7 and UL268/521

OEM/ODM: Welcom

1,Built-in alarm relay (NO)
2,Proven detection performance
3,Sensor base: optional installation mode.
(e.g. Apollo or Wizmart's wiring mode)

SNC-300-SRInternal Relay contact with Form A (NO)

4-Wire Optical Smoke Detector with Relay Output Function

Model SNC-300-SR smoke detector uses a specialized smoke chamber design, which could sense the presence of smoke particles produced by fast combustion or slow smoldering fire.

The SNC-300-SR detectors have a integral relay with from A (NO), connected between the L1 OUT(6) terminal and the –R(3) terminal, its provide one set of volt-free changeover (form A) contacts change state when the detector signals an alarm.

The detector will work with most modern fire alarm control panels\security systems, and meet s the requirements of UL 268 and EN 54-7.

4-Wire Optical Smoke Detector with Relay Output

Specification:

MODEL	SNC-300-SR
DETECTOR CLASS	Optical Smoke
SUPPLY WIRING	4 – WIRE
DESIGN STANDARD	EN 54-7 and UL 268NDnsensitivet)articles (0.5 to 10 mt) furnishings, PVC, plastic, foam, and e alarm signaling systems.ics technolgogy.
APPROVAL	CE; BSI and UL CERTIFICATED
SUPPLY VOLTAGE	24V DC
QUIESCENT CURRENT	60μA @24V
ALARM CURRENT	35mA@12V
TEMPERATURE RANGE	-10℃ to +55℃
HUMIDITY	0% to 95% RH No Condensation
SENSITIVITY	UL:2.3%FT; EN 54:0.15dB/m
IP RATING	IP 43
START-UP TIME	10 Seconds
DIMENSIONS (dia. x height)	102 x 45mm (with Base)
WEIGHTS	130g (with Base)
